Here is the SCAT crankshaft that arrived with the motor. The
SCAT goes back to the original owner.
|
![](1751t.jpg)
Here is the Jeff Green Donovan LT1 and an ERE Iron LT1 in the
background
|
![](1754t.jpg)
The motor arrived set up for dry sump. We are going to go back
to wet sump. Here I'm fitting a Stef's oil pan.
|
![](1755t.jpg)
The rear main caps interfere.
|
![](1756t.jpg)
There is no interference at the front.
|
![](1757t.jpg)
|
![](1758t.jpg)
The old dry sump oil pan also had clearance issues.
|
![](1759t.jpg)
|
![](1760t.jpg)
Test fit of a Titan gerotor oil pump.
|
![](1761t.jpg)
|
![](BilletERE001t.jpg)
Sonny Bryant crankshaft arrived.
|
![](BilletERE003t.jpg)
|
![](BilletERE004t.jpg)
4.000" stroke, (the crank has large SBC400 main journal sizes)
|
![](BilletERE005t.jpg)
|
![](BilletERE006t.jpg)
The head stud kit is standard 7/16"
|
![](BilletERE007t.jpg)
Some of the bores are out of round and with a great amount of taper.
|
![](BilletERE008t.jpg)
The cylinders will need to be bored and honed.
I have a rough mesurment of 4.165" bore. The crankshaft
is 4.000" stroke and using a spare 6" rod with 1.125"
compression height piston as a gauge I get 9.125" block deck
height
|
![](BilletERE010t.png)
Just a quick photo of the SCAT crank storage rust.
|
![](BilletERE011t.jpg)
A few photos of the SCAT crank just prior to removal.
|
![](BilletERE014t.jpg)
This Donovan 400 block has SBC 400 mains and so the previous owner
used inserts under the main bearings to fit a SBC SCAT crankshaft
with 350 mains.
|
![](BilletERE015t.jpg)
SCAT crank is now in a Callies box and will be shipped to the
original owner.
|
![](BilletERE016t.jpg)
Here is the Sonny Bryant 4.000" stroke crankshaft.
|
